Widely used in various industries, including automotive, electronics, consumer goods, and medical devices. They offer advantages such as efficient use of floor space, ease of operation, and versatility in producing a wide range of plastic parts.
| Type | Unit | LZ-600 | ||||
| Injection unit | Screw dia. | mm | 30 | 35 | 40 | |
| Injection pressure | kg/cm2 | 2645 | 1945 | 1485 | ||
| Theoretical shot volume | cm3 | 99 | 135 | 175 | ||
| Shot weight | g | 87 | 119 | 155 | ||
| oz | 3.1 | 4.2 | 5.5 | |||
| Injection rate | cm3/sec | 91 | 125 | 163 | ||
| Screw stroke | mm | 140 | ||||
| Screw rate | rpm | 0-350 | ||||
| Injection speed | mm/s | 130 | ||||
| Temperature section(zone) | - | 5 | ||||
| Clamping unit | Clamping force | tons | 60 | |||
| Opening force | tons | 9.2 | ||||
| Fixed table | Table size | mm | 650*490 | |||
| Tie bar | mm | 490*330 | ||||
| Min. mold thickness | mm | 200 | ||||
| Opening stroke | mm | 200/250 | ||||
| Opening daylight | mm | 400 | ||||
| Electric unit | Ejector force | tons | 1.5 | |||
| Ejector stroke | mm | 37 | ||||
| Max. pressure | kg/cm2 | 140 | ||||
| Oil tank volume | liters | 165 | ||||
| Cooling water volume | liters/hr | 60 | ||||
| System Motor | kw | 7.5 | ||||
| Heater | kw | 6.6 | ||||
| Total wattage | kw | 14.1 | ||||
| Others | Machine weight | tons | 2.7 | |||
| Machine size | m | L2.2*W1.2*H3.5 | ||||
Small footprint, user-friendly operation, strong stability, high production efficiency, wide applicability, easy maintenance, and environmental friendliness. These features make them widely used in various industries.
Welcome to LIZHU,a factory specialized in the production of high-speed and precision vertical injection molding machines boasting over 30 years of expertise.
